Overview Package Size 30.00cm * 30.00cm * 20.00cm Package Gross Weight 5.000kg TPU Covered and Lining Fuel Delivery Hose;
Overview
Basic Info.
Model NO. | Fracflo Hose |
Fire Hose Length | 10-10000m |
Working Pressure | 150-1230psi |
Diameter | 2"-16" |
Lining | With Lining |
Weaving Type | Twill Weaving |
Hose Coupling Structure | Plug-in |
Color | Customize |
Bp | 300-1230psi |
Wp | 150-410psi |
Transport Package | Carton |
Specification | Fracflo Hose |
Trademark | ZYFIRE |
Origin | China |
HS Code | 59090000 |
Production Capacity | 15, 000, 000m/Year |
Packaging & Delivery
Package Size 30.00cm * 30.00cm * 20.00cm Package Gross Weight 5.000kgProduct Description
TPU Covered and Lining Fuel Delivery Hose 1" -16"
Product Description
ZYfire Hose Corporation, founded in 2000, we research and produce Lay flat frac hose, fire hose, rack hose, industrial hose, forestry hose, snow-making hose, irrigation hose, drag hose, potable water hose, No-dig pipe rehabilitation liner, TPR layflat hose, hose couplings, landing valves and other fire fighting equipments.
Fracflo HoseThrough-the-weave TPU frac water hoseCover and Lining: TPU, Ribbed cover or smooth cover.Reinforcement Jacket: High tenacity synthetic jacket.Application: Water transfer FracturingAvailable length: 30m (100ft), 61m (200ft), 90m (300ft), 100m (330ft), 200m (660ft), 300m (990ft), 400m (1320ft)Hose can be with glow line on special requests!The reinforcement is made from circular woven filament polyester yarn. The "extrusion through-the-weave" production method gives a very strong bonding between cover and lining as well as firmly encapsulating the woven polyester.The hose has high resistance against commonly used chemicals and has excellent resistance to UV radiation, hydrolysis and fungus degradation. The abrasion resistance of the TPU is one of the highest available, making the hose ideal for use in the extremely abrasive environment in open pit mines.The outer cover has been designed with extra thickness in order to add wear & tear material. This extends the useful lifespan of the hose.Extra abrasion resistance for rugged terrain and extreme conditions. Resistant to oil and chemicals. UV Stabilized.Abrasion: 4000 DIN cyclesTemperature range: -50ºC to 80ºC (-58ºF to +176ºF)I.D. | Tolerance | Wall Thickness | Service Pressure | Minimum Burst Pressure | Weight | Elongation At WP% | Expansion At WP% | Temperature Range | |||||
inch | mm | mm | inch | mm | psi | psi | Lbs/ft | Tolerance lbs/ft | Kg/m | Tolerance kg/m | max | max | |
2" | 51 | 51-53 | 0.071±0.008 | 1.8±0.2 | 250 | 750 | 0.28 | ±0.067 | 0.42 | ±0.1 | ≤1 | ≤8 | -50 to +80 (-58 to +176) |
3" | 76 | 76-78 | 0.126±0.012 | 3.2±0.3 | 250 | 750 | 0.64 | ±0.067 | 0.95 | ±0.1 | ≤1 | ≤8 | |
4" | 102 | 102-104.5 | 0.11±0.012 | 2.8±0.3 | 200 | 600 | 0.72 | ±0.067 | 1.08 | ±0.1 | ≤1 | ≤8 | |
4" | 102 | 102-104.5 | 0.138±0.012 | 3.5±0.3 | 250 | 750 | 0.94 | ±0.067 | 1.4 | ±0.1 | ≤1 | ≤8 | |
4" | 102 | 125-127.5 | 0.138±0.012 | 3.5±0.3 | 300 | 900 | 0.87 | ±0.067 | 1.3 | ±0.1 | ≤1 | ≤8 | |
5" | 125 | 154-157 | 0.165±0.012 | 4.2±0.3 | 150 | 300 | 1.2 | ±0.134 | 1.8 | ±0.2 | ≤1 | ≤8 | |
6" | 152 | 154-157 | 0.118±0.012 | 3±0.3 | 150 | 450 | 1.07 | ±0.067 | 1.6 | ±0.1 | ≤1 | ≤8 | |
6" | 152 | 154-157 | 0.15±0.012 | 3.8±0.3 | 250 | 750 | 1.41 | ±0.134 | 2.1 | ±0.1 | ≤1 | ≤8 | |
6" | 152 | 154-157 | 0.165±0.012 | 4.2±0.3 | 300 | 900 | 1.74 | ±0.201 | 2.6 | ±0.2 | ≤2 | ≤8 | |
6" | 152 | 154-157 | 0.228±0.016 | 5.5±0.4 | 640 | 1230 | 2.11 | ±0.201 | 3.15 | ±0.3 | ≤2 | ≤8 | |
6" | 152 | 154-157 | 0.228±0.016 | 5.6±0.4 | 725 | 1830 | 2.14 | ±0.134 | 3.5 | ±0.3 | ≤2 | ≤8 | |
8" | 204 | 204-207 | 0.15±0.012 | 3.8±0.3 | 200 | 600 | 1.94 | ±0.134 | 2.9 | ±0.2 | ≤1 | ≤10 | |
8" | 204 | 204-207 | 0.177±0.016 | 4.5±0.4 | 300 | 900 | 2.28 | ±0.134 | 3.4 | ±0.2 | ≤1 | ≤10 | |
10" | 254 | 256-259 | 0.165±0.016 | 4.2±0.4 | 200 | 600 | 2.75 | ±0.201 | 4.1 | ±0.2 | ≤1 | ≤10 | |
10" | 254 | 256-259 | 0.197±0.016 | 5.0±0.4 | 300 | 900 | 3.75 | ±0.201 | 5.6 | ±0.3 | ≤2 | ≤8 | |
12" | 306 | 306-311 | 0.165±0.016 | 4.2±0.4 | 150 | 450 | 3.33 | ±0.201 | 4.97 | ±0.3 | ≤1 | ≤8 | |
12" | 306 | 306-311 | 0.228±0.0197 | 5.8±0.5 | 200 | 600 | 4.3 | ±0.201 | 6.4 | ±0.3 | ≤2 | ≤8 | |
14" | 356 | 356-360 | 0.205±0.0197 | 5.2±0.5 | 150 | 450 | 4.96 | ±0.201 | 7.4 | ±0.3 | ≤1 | ≤8 | |
16" | 406 | 406-410 | 0.205±0.0197 | 5.2±0.5 | 150 | 300 | 5.09 | ±0.201 | 7.6 | ±0.3 | ≤1 | ≤10 |
